SPECIFICATION
Type OWD-W5G
Ozone Water Output 0.5 - 1 ppm
Water Flow 4-7 LPM
Output Pressure Max. 2.5 Mpa
Oxygen Flow 1 L/min
Inlet / Outlet Water 3/4" Female Tread
Cooling Methode Air Cooled
Working Temperature 5 °C to 40°C
Ambience Temp. 75%
Ozone Destructor No
Power 55 W
Voltage Rate 220 V
Dimension (mm) 360 x 270 x 120
Gross Weight 5 Kg

SPECIFICATION
Type OWD-M5G
Ozone Water Output 1 - 3 ppm
Water Flow Max. 10 LPM
Output Pressure Max. 2.5 Mpa
Oxygen Flow 1 L/min
Inlet / Outlet Water 1/2" Male Tread
Cooling Methode Air Cooled
Working Temperature 5 °C to 40°C
Ambience Temp. 75%
Ozone Destructor No
Power 300 W
Voltage Rate 220 V
Dimension (mm) 370 x 250 x 300
Gross Weight 12.6 Kg

SPECIFICATION
Type OWD-M10G
Ozone Water Output 1 - 18 ppm
Water Flow 30 LPM
Output Pressure Max. 4 Mpa
Oxygen Flow 3 L/min
Inlet / Outlet Water 3/4" to 1/2" Male Tread
Cooling Methode Air Cooled
Working Temperature 5 °C to 40°C
Ambience Temp. 85%
Ozone Destructor Yes
Power 850 W
Voltage Rate 220 V
Dimension (mm) 700 x 450 x 705
Gross Weight 59.5 Kg
